Kona Ouroboros CR (36e) Metallic Blue
| Availability: | In stock (1) |
Ouroboros CR
Whether you’re a gravel-loving mountain biker or a mountain-bike-loving gravel biker, the Ouroboros Carbon is the lure to catch the attention of both. We’ve made sure each coin spent is met with corresponding value in shred performance. The Ouroboros Carbon is meant for big things, so we put big things on it – like fat tires, large rotors, a mountain standard dropper post width, and a low, yet wide gear range. Hop on and let the journey unfold.
Geometry
| Size | 48 | 50 | 52 | 54 | 56 | 58 | |
| 1 | ST Length | 410 | 410 | 455 | 455 | 500 | 535 |
| 2 | TT Length | 530 | 544 | 559 | 576 | 593 | 613 |
| 3 | Reach | 380 | 385 | 390 | 395 | 400 | 405 |
| 4 | Stack | 560 | 575 | 590 | 610 | 630 | 660 |
| 5 | Standover | 716 | 721 | 758 | 768 | 806 | 840 |
| 6 | HT Angle | 69.5 | 69.5 | 69.5 | 69.5 | 69.5 | 69.5 |
| 7 | HT Length | 115 | 131 | 147 | 172 | 193 | 225 |
| 8 | ST Angle | 75.0 | 74.5 | 74.0 | 73.5 | 73.0 | 72.5 |
| 9 | CS Length | 445 | 445 | 445 | 445 | 445 | 445 |
| 10 | BB Drop | 75 | 75 | 75 | 72 | 72 | 72 |
| 11 | BB Height | 292 | 292 | 292 | 295 | 295 | 295 |
| 12 | Wheelbase | 1059 | 1069 | 1080 | 1094 | 1106 | 1123 |
| 13 | Front Center | 625 | 635 | 646 | 659 | 671 | 687 |
| 14 | Fork Length | 420 | 420 | 420 | 420 | 420 | 420 |
| 15 | Fork Offset | 55 | 55 | 55 | 55 | 55 | 55 |
| Frame: | Kona Carbon |
| Fork: | Fox TC32 Performance GRIP damper, 40mm travel, Tapered, 100x12mm |
| Crankset: | SRAM Apex 1 DUB Wide crankarms w/SRAM Apex 38t AL direct mount Chainring w/SRAM Press-Fit 86.5 DUB Wide BB |
| Derailleur Front: | n.a. |
| Derailleur Rear: | SRAM Apex 12 Eagle |
| Cassette: | SRAM PG-1230 11-50t 12 speed |
| Shifters: | SRAM Apex 12 |
| Brakes: | SRAM Apex Flat Mount Hydraulic calipers w/SRAM Centerline 6-bolt 180mm rotors w/SRAM Apex 12 levers |
| Wheels/Rims: | WTB KOM Team i27 700c 32h rims w/Stainless Black 14g spokes w/Formula 100 x 12 6-bolt (FR) Formula 142 x 12 6-bolt, 11sp Road freehub (rr) |
| Tires: | Maxxis Ravager 700 x 50 TR EXO |
| Handlebar: | Kona 20-degree flare, 48: 440mm; 50: 460mm; 52-54: 480mm; 56: 500mm; 58: 520mm |
| Stem: | Kona 6-degree rise, 48-52: 40mm; 54-58: 50mm |
| Saddle: | WTB Volt Medium Steel SL |
| Seatpost: | TranzX Dropper +RAD Internal, 31.6mm, 125mm travel |
| Color: | Gloss Metallic Blue w/ Metallic Silver Decals |
| Misc: |
